Product Detail

160 lm/w

Up to 1000W

5 Years Warranty

flg-stadium-light-1

FLG stadium light PC lens

Beam Angle:

20°/40°/60° PC lens

Heat Sink:

Can be adjustable angle!

FLG stadium light heatsink

led stadium lighting

Lighting Simulation:

Football field field

Certificate & Report:

CE, RoHS, IP66.

FLG CE, RoHS, IP66 cetificate

Product Application Cases

FLG Airport Lighting Application Case 4

FLG Airport Lighting Application Case 3

FLG Airport Lighting Application Case 2

FLG Airport Lighting Application Case 1

Product Specification

Product Specifications

Model No.	KML-FL200G	KML-FL240G	KML-FL400G	KML-FL500G	KML-FL600G	KML-FL700G	KML-FL800G	KML-FL1000G
Input Power	200W	240W	400W	500W	600W	700W	800W	1000W
Lumen Output	32,000 lm	38,400 lm	64,000 lm	80,000 lm	96,000 lm	112,000 lm	128,000 lm	160,000 lm
Efficacy	160 lm/w
Power Factor	PF>0.90
Input Voltage	AC100-277V/AC220-240V, 50Hz/60Hz
CCT	3000K/4000K/4500K/5000K/5700K/6500K
CRI	Ra≥70 (Ra≥80 optional)
LED Chip	LUMILEDS
Housing Color	Black/Silver
IP Rating	IP65
Material	Aluminum, PC
Operating Temperature	-30°C to +50°C
Operating Humidity	10% to 90% RH
Certificate & Report	CE, RoHS, IP66
Lifespan	L70B10 100,000 hours
Warranty	7 years

Download

Download Details of LED Stadium Light – KML-FLG
