Product Detail
170lm/w & 150lm/w
Up to 240W
5 Years Warranty
Beam Angle:
Type I |Type II | Type III | Type IV PC lens
Installation angle adjustment:
±15°, 5° as a unit.
Control (optional):
Daylight | ZHAGA | NEMA | LoRa
Product Specification
Product Specifications
| Model No. | KML-SL18-30 | KML-SL18-60 | KML-SL18-100 | KML-SL18-150 | KML-SL18-200 | KML-SL18-240 |
| Power | 30W | 60W | 100W | 150W | 200W | 240W |
| Lumen Output | 5,100 lm | 10,200 lm | 17,000 lm | 25,500 lm | 34,000 lm | 40,800 lm |
| Spigot Size | Ø45mm | Ø60mm | |||||
| Luminous Efficacy | 170 lm/w (150 lm/w optional) | |||||
| Power Factor | PF>0.90 | |||||
| Input Voltage | AC100-277V/AC220-240V, 50Hz/60Hz | |||||
| CCT | 3000K | 4000K | 4500K | 5000K | 5700K | 6500K | |||||
| CRI | Ra≥70 (Ra≥80 optional) | |||||
| LED Chip | SMD3030 | SMD5050 | |||||
| Housing Color | Gray | |||||
| IP Rating | IP66 | |||||
| IK Rating | IK08 | |||||
| Material | Aluminum, Glass, PC | |||||
| Operating Temperature | -30°C to +50°C | |||||
| Operating Humidity | 10% to 90% RH | |||||
| Lifespan | L70B10 100,000 hours | |||||
| Warranty | 5 years | |||||
